National EMF-EMI Site Surveys

Industrial, Scientific, Medical

ELEXANA provides nationwide EMF and EMI site surveys for commercial, industrial, and government facilities. Using ISO 17025-calibrated equipment and IEEE-standard protocols, we deliver accurate diagnostics for safety, compliance, and sensitive electronic system protection.

ELEXANA is an award-winning industry leader with an international reputation for solving complex Electromagnetic Interference (EMI), Electromagnetic Compliance (EMC) Designs, Electromagnetic Field Radiation (EMF), and Radio Frequency Interference (RFI).

ISO 17025-certified, calibrated instruments for all high-risk measurements, assured accuracy, verifiable, replicable, and traceable official reports.

Our EMI/EMF survey measurements include GPS coordinates and time stamps.

ELEXANA provides EMI and EMF Testing, Analysis, Troubleshooting, Advanced Data Logging, Surveys, Assessments, and Mitigation Consulting.

Why Be Concerned About EMI?

Electromagnetic interference (EMI) causes latency, malfunction, and sluggish performance to fine electronics such as computers, medical devices and equipment, pacemakers, financial trading platforms, graphic software, recording equipment, etc.

With the exponential increase of wireless technologies in New York City, EMI has become a common vernacular. Line noise, harmonic transients, dirty electricity, RFI (radio frequency interference), and electromagnetic coupling are synonyms.

How Do You Know It’s EMI?

An easy way to tell if you have an EMI issue is to look for the presence of:

Unwanted screen images, patterns, static, or artifacts.
Overheating of any metal enclosures. Are enclosures very hot to the touch?
Motor failures from overheating.
Fuses blowing for no apparent reason.
Static or interference on sound or voice communication.
The electronic equipment is shutting down for no apparent reason.
The computer malfunctions or locks up.
Flickering of fluorescent or LED lights.
Blinking incandescent lights.

Electromagnetic energy coupled to circuitry and components causes electromagnetic interference (EMI).

The Four Types of Electromagnetic Coupling

1. Conductive Coupling occurs when the coupling path between the source and the receptor forms direct electrical contact with a conducting body.

An example of Conductive Coupling occurs when a municipal water service pipe has a reverse neutral stray current, and the lightning protection system ground wire connected to it conducts this neutral current back onto the neutral bus of an electrical panel. Line EMI or signal-to-noise can occur from the same or opposite directions.

We call this common impedance when the signal-to-noise ratio appears in phase in the same direction on both conductors.
We call this differential impedance when the signal-to-noise ratio appears out of phase, in the opposite direction on both conductors.

2. Inductive Coupling occurs when a strong electromotive force intersects an electrical conductor within a magnetic field, causing the original magnetic field to become distorted. James Clerk Maxwell, who preceded Albert Einstein, mathematically described this process as "Faraday's Law of Induction." An example of inductive coupling is when an underground power line runs close enough to a water pipe that the pipe acquires leakage current.

3. Capacitive Coupling occurs when two fluctuating electrical fields co-exist between two adjacent conductors, thereby inducing a change in voltage on the receiving conductor receptor. Capacitive Coupling is among the most intriguing and challenging for the new student. We see this occurring when we turn off the branch circuit in a room and register that the electric field has become stronger. This happens because the electrician had strung wires in parallel from different branch circuits.

4. Radiative Coupling occurs when the distance exceeds one wavelength between the source point and the receptor. The source point emits or radiates an electromotive force across space that a conductor receives. An example is a cell transmitter sending signals that inadvertently couple onto your equipment’s wiring. This is termed “unintentional coupling.”

Welding equipment can stress pacemaker function.

The human exposure reasons for testing can range from testing for site compatibility for an employee's pacemaker or defibrillator to determine if it will function throughout the day without suffering interference issues, to employees claiming that their work environment is causing them harm, or has caused their illness.

A medical device manufacturer will have extensively stress-tested their products for EMI immunity before going to market, ensuring their relative safety. Nevertheless, severe electromagnetic environmental stress will cause any electronic device to fail. The patient's doctor can make EMI threshold levels of a biomedical device available; then you can call on Elexana to test your facility.

Site testing should be rigorous and thorough. Pacemakers and other biomedical implants require specific, certified, calibrated equipment. The surveyor needs an OSHA certification and must have experience working in industrial sites. The company must carry General Liability and Professional Liability Insurance.

If an employee complains about the EMI or EMF levels at the workplace, the situation is somewhat different for the EMF Consultant. Often, we see that the employee has purchased a meter on the internet and finds that their measurements exceed the specific standards. However, there are many problems with these types of employee measurements.

First, these meters are usually uncalibrated and skew readings towards an exaggerated high side. Also, inexpensive meters made for amateurs are prone to spurs or internal circuitry overload, often presenting false peak readings to the high side. Another mistake I see "professionals" make in measuring technique is placing a meter too close to the source. We have all seen the amateur put the RF meter to the cell phone or wifi or a Trifield EMF meter to an electrical panel. (It is one thing to do this for a photo-op, but another for a survey.)

Most meters cannot be measured at the extreme of the near field. Indeed, no RF meters can be measured accurately in the near field. A third mistake I see amateurs and some "professionals" make is that they do not identify the correct energy source; instead, they measure the correct energy but identify the wrong energy cause.

So, surveys are measured from a source point, and typical industrial surveys are measured on a grid or a straight line. Often, a factory will have support columns marking each section. These marked sections make it easy to document a grid survey. Sometimes, a GPS enhances the measuring and documentation process. Other times, using our NFA 1000s, we can data log and map simultaneously. (See the chart.) (Note: Calibration of the NFA1000 takes place in Germany.)

Grid surveys can be helpful. After identifying elevated levels, an overlap survey will be added to determine the correct sources and proper mitigation.

EMI Services

Equipment Interference Issues and Concerns: On-site EMI troubleshooting, diagnostics, and attenuation for laboratory and medical equipment, metal detectors, surveillance equipment, autonomous vehicles, trading platforms, broadcast, video, and music recording.
Industrial EMI diagnostics and analysis for AIC - Artificial Intelligence Compatibility,™
Research laboratory EMI diagnostics and analysis for SEM/TEM on-site electromagnetic compliance to specifications,
Medical laboratory EMI diagnostics and analysis for MRI, NMR, EKG, and EEG equipment on-site compliance,
Electromagnetic interference (EMI) attenuation for peak electronic, computer performance, and information technology equipment,
RFI, E-Field, B-Field, GIC, H-Field, and AC magnetic shielding design,
Architectural and engineering EMI/RFI consultations,
EMC/EMI Pre-Compliance testing at your facility,
Long-term data logging and RF masking,

Depending on the Type of Space or Business to Survey, there can be Special Considerations for an EMI Survey. Below are the most often called upon.

Key Steps in a Hospital EMI Survey

1. Planning & Preparation

Define the scope: entire hospital, specific wings (e.g., ICU, radiology), or sensitive rooms.
Identify critical equipment that could be affected.
Gather hospital floor plans, device lists, and known EMI trouble areas.
Coordinate with hospital staff to schedule minimal-disruption times.

2. On-Site Survey Measurements

Use calibrated measurement equipment:

Spectrum analyzers
Field strength meters (for electric, magnetic, and RF fields)
Broadband and narrowband antennas or probes

Measure at:

Multiple locations (patient rooms, operating rooms, equipment bays, ICU, MRI suites).
Different times (day vs. night, high-activity vs. low-activity periods).
Across relevant frequency ranges (often from kHz to GHz, depending on equipment sensitivity).

3. Source Identification

Identify any EMI sources:

Internal: hospital equipment (switching power supplies, monitors, RF emitters, wireless networks).
External: nearby cell towers, radio/TV transmitters, power lines, elevator motors.

Map interference levels relative to equipment or patient areas.

4. Comparison to Standards

Compare findings to relevant standards:

IEC 60601-1-2 (medical equipment EMC requirements).
FCC or ICNIRP exposure limits.
Hospital-specific or national guidelines for electromagnetic environments.

5. Documentation & Reporting

Create detailed reports:

Maps showing measurement points and field strengths.
List of equipment at risk or affected.
Summary of compliance vs. non-compliance.
Recommendations for mitigation if needed (shielding, relocation, filtering, operational changes).

6. Recommendations & Follow-Up

Provide technical recommendations:

Reducing emissions at the source.
Adding shielding or filters.
Rearranging layouts or equipment placement.

Optionally schedule follow-up testing after mitigation.

7. Special Considerations in Hospitals

Patient safety: Surveys must be done carefully to avoid disrupting critical care.
Equipment diversity: Medical devices have varying EMC tolerance, and MRI rooms have different needs from infusion pumps.
Strict standards: Medical environments are highly regulated for EMC because malfunctions can be life-threatening.
Environmental factors: Hospitals often have complex infrastructure, including elevators, HVAC, wireless networks, and paging systems, contributing to EMI.

An EMI survey of a manufacturing facility is designed to assess and map the electromagnetic environment across the plant floor to ensure that electromagnetic interference does not disrupt sensitive equipment, control systems, and communication networks and that the facility meets regulatory or operational EMC requirements.

Here’s what’s typically involved:

Key Steps in a Manufacturing Facility EMI Survey

1. Planning & Scoping

Define the scope:
Are you surveying the entire facility or specific zones (e.g., production lines, control rooms, testing labs, cleanrooms)?
Identify critical systems:
What equipment is sensitive to EMI? Examples: PLCs, CNC machines, robotic controllers, sensors, wireless networks, safety systems.
Gather background data:
Floor plans, equipment lists, known problem areas, reports of past system glitches or failures.

2. Measurement & Data Collection

On-site EMI measurements using specialized equipment:

Spectrum analyzers
Field strength meters (electric and magnetic fields)
Broadband and narrowband antennas
Conducted EMI probes for power lines or data lines

Measurement areas include:

Production floors (especially near heavy machinery, motors, variable frequency drives [VFDs], welders)
Control rooms (where sensitive electronics are concentrated)
Communication areas (e.g., wireless networks, SCADA systems)
Power distribution panels and grounding systems

Frequency ranges:
Typically measured from low-frequency sources (power line harmonics, 50/60 Hz) up to high-frequency ranges (MHz–GHz), depending on what systems are present.

3. Identify EMI Sources

Pinpoint primary emission sources, which might include:

Motors and generators
Welders
Inverters, VFDs, or switching power supplies
Industrial communication systems (RF or wireless)
Poorly grounded or shielded equipment

Map out sensitive areas where equipment might be vulnerable.

4. Compare Against Standards

Reference applicable standards:

IEC 61000 family (EMC immunity and emission standards)
FCC Part 15 (for unintentional emitters)
Industry-specific guidelines (automotive, aerospace, semiconductor, etc.)

Assess whether emissions or field strengths exceed acceptable limits or create operational risks.

5. Documentation & Reporting

Provide a detailed report including:

Measurement data and summary tables
Maps of the facility with EMI hotspots marked
Identified emission sources and affected equipment
Compliance assessment relative to relevant standards

6. Mitigation Recommendations

Suggest practical solutions, such as:

Adding shielding or filters
Improving grounding and bonding
Separating sensitive cables or relocating sensitive equipment
Installing power line filters or line conditioners
Upgrading facility infrastructure if needed

7. Optional Follow-up

Perform post-mitigation surveys to confirm effectiveness.
Provide ongoing monitoring plans for high-risk environments.

8. Special Considerations in Manufacturing Facilities

High-power equipment: Heavy machinery can generate strong conducted and radiated emissions.
Harsh environments: Dust, temperature, or vibration may affect EMI behavior.
Process uptime: Surveys often need to be scheduled around production to avoid downtime or interference with operations.
Safety systems: Ensure surveys do not disrupt safety circuits or emergency systems.

An EMI survey of a science research lab is a specialized process for assessing and managing the electromagnetic environment so that highly sensitive instruments and experiments are not compromised by electromagnetic interference (EMI).

Science labs — especially in physics, materials science, biology, and quantum research — often use equipment (like electron microscopes, NMR machines, atomic clocks, or photonics setups) that can be extremely sensitive to weak EMI or magnetic fields.

Here’s what’s typically involved:

Key Steps in an EMI Survey of a Science Research Lab

1. Scoping & Preparation

Define the scope:
Are you surveying the entire lab building, specific rooms (like microscopy labs, cleanrooms, or shielded rooms), or specific equipment stations?
Identify sensitive equipment and experiments:
Make a detailed list of instruments most vulnerable to EMI (e.g., scanning electron microscopes, NMR spectrometers, cryogenic setups, precision balances, optical tables).
Review infrastructure and known issues:
Gather lab layout drawings, equipment placement maps, and any history of unexplained malfunctions or anomalies.

2. Measurement & Data Collection

On-site EMI/EMF measurements using high-precision equipment:

Spectrum analyzers (for RF emissions).
Field strength meters and low-frequency magnetometers (for magnetic fields, often critical in labs).
Near-field probes are looking for local sources.
Broadband antennas or specialized sensors, depending on the frequency range.

Frequency ranges measured:

Low frequency (powerline: 50/60 Hz, harmonics).
Mid-frequency (kHz to MHz, from switching supplies or lab electronics).
High frequency (MHz to GHz, from wireless devices, nearby transmitters).

Measurement locations:

Near sensitive instruments.
Around power lines, electrical panels, HVAC systems, and elevators.
External sources near the lab building (cell towers, broadcast antennas).

Time considerations:
Some measurements may need to be taken during typical lab operations and off-hours to detect intermittent or variable sources.

3. Identify EMI Sources

Look for internal sources like:

Switching power supplies.
Fluorescent or LED lighting drivers.
Nearby laboratory equipment (centrifuges, vacuum pumps, lasers, RF generators).
In-lab wireless or communication systems.

Check for external EMI threats:

Nearby cell towers or radio transmitters.
Power lines or transformers are adjacent to the lab building.

4. Compare Against Standards and Sensitivity Thresholds

Unlike industrial or hospital environments, labs often set their own EMI limits based on instrument manufacturer specifications, rather than formal regulatory thresholds.
Assess if measured levels pose a risk to:

Instrument precision and accuracy.
Data quality in experiments.
System stability over time.

5. Documentation & Reporting

Provide a comprehensive report with:

Measurement data (tables, plots, spectrograms)
Maps of the lab showing EMI levels and hotspots
Identified sources and potential problem areas
Recommendations for reducing EMI or isolating sensitive setups

6. Recommendations & Mitigation

Propose solutions such as:

Relocating or shielding sensitive equipment.
Installing magnetic shielding (mu-metal, active cancellation).
Improving grounding and bonding practices.
Filtering power lines and signal cables.
Implementing operational controls (e.g., limiting use of specific devices during sensitive experiments).

7. Special Considerations in Research Labs

Extremely low tolerance for noise: Instruments like NMR, SQUID, or electron microscopes may require ultra-low magnetic or RF environments.
Shared spaces: Multiple research groups may share space, creating complex cross-interference risks.
Unique equipment: Custom-built experimental setups may lack formal EMC certification and need tailored approaches.
Dynamic environments: Labs often evolve rapidly, adding or moving equipment frequently, causing the EMI environment to change.

An EMI survey of an office building typically assesses the electromagnetic environment to ensure that office equipment, networks, and potentially sensitive electronic systems (like servers, medical office equipment, or industrial control systems) operate without interference. This type of survey is essential in offices with high-density electronic equipment or near critical systems (e.g., IT rooms and data centers). The goal is to prevent any disturbances that could affect the performance of sensitive equipment or disrupt communications.

Key Steps in an EMI Survey of an Office Building

1. Planning & Scoping

Define the scope:
Are you surveying the entire office building or specific areas, such as server rooms, meeting rooms with AV equipment, or floors with sensitive electronics?
Identify sensitive equipment and areas:
Determine which devices or systems are critical and might be impacted by EMI, such as:

Network infrastructure (servers, routers, switches)
Medical or industrial equipment (if the building houses any specialized offices or departments)
Wireless systems (Wi-Fi, Bluetooth, Zigbee)
AV equipment, including microphones and projectors
Office electronics (computers, fax machines, printers)

Gather the facility layout:
Obtain floor plans, equipment placement maps, and past reports of equipment malfunction or unexplained issues.

2. Measurement & Data Collection

On-site measurements:
Use calibrated equipment to assess EMI levels, including:

Spectrum analyzers for broad-spectrum RF interference
Field strength meters (electric and magnetic field strengths)
Broadband and narrowband antennas or probes (depending on the frequencies you're measuring)
Conducted EMI measurement devices (for power lines, data lines, and communication cables)

Measurement locations:

Near IT equipment, server rooms, and high-density electronic areas
Throughout the office areas to map EMI levels (from desktop devices, fluorescent lights, wireless access points, etc.)
Around electrical panels and HVAC systems that may generate EMI
In conference rooms with AV equipment or high-performance wireless devices

Frequency ranges:

Low-frequency ranges (e.g., power-line harmonics, 50/60 Hz)
High-frequency ranges (for wireless devices, Wi-Fi, Bluetooth, mobile communication)

Measurement timing:
Some measurements may need to be taken during peak office hours (when equipment is in use) and during off-hours to check for intermittent or low-level sources of interference.

3. Identify EMI Sources

Internal sources:
Look for equipment that may emit unwanted electromagnetic interference, including:

Power supplies, transformers, and UPS systems
Computers, monitors, and printers
Networking equipment (routers, switches, and wireless devices)
Fluorescent lighting or LED drivers
Electrical systems (motors, elevators, HVAC systems)

External sources:
Consider external threats such as:

Nearby cell towers or radio transmitters
Power lines or electrical substations near the building
Radio or TV broadcasts

4. Comparison to Standards & Thresholds

Regulatory standards and compliance:
Compare findings against relevant standards such as:

FCC Part 15 for unintentional emissions from electronic devices
IEC 61000 series for immunity and emissions
ISO 14644-1 (for cleanroom-type environments with strict control)

These standards outline the acceptable levels of electromagnetic emissions for various environments.
Sensitivity thresholds:
Assess if EMI levels are within acceptable limits for sensitive office equipment or communication systems, ensuring equipment performance does not degrade.

5. Documentation & Reporting

Provide a detailed report that includes:

Measurement data is often represented in graphs or tables.
EMI levels in specific areas of the building.
Maps or diagrams of the office, showing hotspots of interference.
Comparison with applicable standards and limits.
List of identified EMI sources and their potential impacts on sensitive equipment.

6. Recommendations & Mitigation Strategies

Identify sources of excessive EMI and suggest corrective measures, such as:

Shielding or relocating noisy equipment.
Adding filters to power lines or data cables.
Improving the grounding of sensitive equipment or systems.
Relocating or reconfiguring wireless networks to minimize interference.
Installing dedicated EMI control rooms or isolating specific electrical circuits.

7. Optional Follow-up & Monitoring

After implementing mitigation measures, follow-up measurements will be performed to ensure that the EMI levels have been reduced to acceptable levels.
For larger facilities, ongoing EMI monitoring may be suggested to track environmental changes over time (especially in high-traffic or high-density areas).

8. Special Considerations for Office Buildings

Diverse equipment: Offices contain many devices (computers, printers, networking equipment, and AV tools) that might emit EMI, but at low levels.
Wireless communications: Offices often have wireless networks and Bluetooth devices, making RF interference a key consideration.
Energy systems: HVAC, lighting, and elevators can all be significant sources of low-frequency EMI.
Building layout: Open-plan offices vs. enclosed rooms can influence how EMI propagates. Sensitive areas like conference rooms or server rooms may need more detailed analysis.

Summary of an EMI Survey in an Office Building

Identify equipment and areas of concern.
Measure electromagnetic emissions across relevant frequencies.
Compare findings against industry standards.
Map the building to visualize EMI hotspots.
Recommend solutions and mitigation steps.

An EMI survey of a high-rise residential building is focused on assessing and managing electromagnetic interference (EMI) to ensure that the residents' electronic devices, communication systems, and critical systems (e.g., elevators, security systems, Wi-Fi) are not disrupted by external or internal sources of EMI. In high-rise buildings, interference can come from various sources, such as power lines, neighboring buildings, and internal equipment like HVAC systems or electronic appliances.

Here's what’s typically involved in an EMI survey for a high-rise residential building:

Key Steps in an EMI Survey of a High-Rise Residential Building

1. Planning & Scoping

Define the survey scope:
Is the survey for the entire building, a specific floor, or certain areas (e.g., residential units, common areas, mechanical floors)?

Consider the critical areas, like electrical panels, communication rooms, Wi-Fi routers, elevator systems, and high-tech appliances (smart fridges, thermostats).

Identify sensitive equipment:
High-rise buildings often have a variety of electronics, such as:

Home appliances (smart TVs, fridges, dishwashers, air conditioners)
Communication systems (Wi-Fi, cellular, satellite TV)
Security systems (CCTV, access control)
Elevators, lighting systems, and HVAC

Gather building layout:
Obtain floor plans, building wiring diagrams, and information about known sources of EMI (e.g., power lines, nearby cell towers, or electrical substations).

2. Measurement & Data Collection

On-site EMI measurements:
Use specialized equipment to measure EMI at key locations in the building:

Spectrum analyzers for broad-spectrum RF interference (from cell phones, Wi-Fi, or other wireless devices).
Field strength meters (electric and magnetic field strengths, particularly for low-frequency EMI from power lines and transformers).
Conducted EMI measurement devices to check for interference in electrical lines or communication cables (e.g., telephone lines, coaxial cable for TV).

Measurement areas include:

Residential Units: In living rooms, bedrooms, kitchens, and places where sensitive equipment is used (e.g., computers, TVs, medical devices like CPAP machines).
Common Areas: Hallways, lobbies, and shared spaces where wireless networks or intercom systems may be used.
Mechanical/Electrical Rooms: Areas housing electrical panels, transformers, and HVAC systems, as they often emit EMI.
Elevators and Emergency Systems: These systems have motors, controllers, and signaling to generate EMI.

Time considerations:
Measurements should be performed during typical usage hours (when residents are active) and during off-hours (to capture background EMI levels).

3. Identify EMI Sources

Internal sources:

Household appliances: HVAC units, air conditioning, refrigerators, microwaves, washing machines.
Building systems: Electrical transformers, elevator motors, lighting, and water pumps.
Personal electronic devices: Computers, televisions, Wi-Fi routers, smartphones, cordless phones.
Wireless devices: Bluetooth devices, smart home systems, baby monitors.

External sources:

Nearby external transmitters include radio towers, cell towers, and broadcast antennas.
Power lines and electrical substations are near the building.
EMI from neighboring buildings or commercial structures.

4. Comparison to Standards & Thresholds

Regulatory standards and guidelines:

FCC Part 15: Addresses EMI from unintentional emitters like household electronics and appliances
In residential and commercial environments, IEEE and IEC standards govern general electromagnetic compatibility (EMC) and immunity levels.
Building codes and residential guidelines: Minimum EMI levels in buildings are needed to ensure safe and reliable operation of electronic systems.

Assess EMI impact on equipment:
Determine if any measured EMI levels are likely to cause interference with sensitive electronics, such as malfunctioning communication systems, disrupted Wi-Fi networks, or degraded performance of household appliances.

5. Documentation & Reporting

Provide a detailed report including:

Measurement data, visualized in graphs or tables
EMI levels in specific locations (identified hot spots, such as rooms with high-frequency interference)
Identified sources of EMI (both internal and external)
Compliance status: Does the building meet relevant standards or exceed acceptable limits?

Include recommendations for mitigation, if necessary.

6. Recommendations & Mitigation Strategies

Propose solutions to reduce or eliminate identified EMI sources:

Shielding: Adding shielding to sensitive equipment or specific areas (e.g., using Faraday cages for Wi-Fi routers or high-tech appliances).
Relocation: Suggest relocation of devices that emit excessive EMI (e.g., moving power transformers away from living areas).
Filtering: Installing filters for power lines or communication cables to block high-frequency interference.
Grounding: Improving grounding and bonding of the building’s electrical system to reduce low-frequency interference.
Reconfiguration: Adjusting Wi-Fi network setup, minimizing interference from devices like microwaves or cordless phones.

7. Optional Follow-up & Monitoring

After implementing mitigation steps, conduct follow-up measurements to ensure that EMI levels are reduced to acceptable levels and that the proposed solutions work effectively.
In buildings with continuous concerns (e.g., dense Wi-Fi networks or proximity to radio towers), continuous monitoring may be recommended through periodic surveys or the installation of EMI monitoring systems.

8. Special Considerations for High-Rise Residential Buildings

Proximity to external sources: High-rise buildings can be more exposed to external EMI from nearby radio towers, cellular networks, or electrical substations.
Building density: A high concentration of electronic devices in close quarters can create complex EMI patterns that may need detailed analysis.
Shared infrastructure: Many buildings have shared services like heating, cooling, and electrical panels that can generate interference. EMI issues may be more pronounced in older buildings with outdated systems.
Sensitive equipment: Consider any special needs for equipment such as medical devices (e.g., pacemakers or CPAP machines) that residents may use.

Summary of an EMI Survey in a High-Rise Residential Building:

Identify sources of interference inside and outside the building.
Measure EMI levels across a range of frequencies in different building areas.
Compare against standards to assess compliance and impact on sensitive devices.
We recommend mitigation strategies to reduce EMI and ensure proper equipment functionality.
Follow-up testing to ensure that solutions have worked.
